NFC Multi Tag Reader/Writer
The ZD-FN5 NFC reader/writer is a highly integrated non-contact communication module that operates at 13.56MHz and supports 16 NFC tag readers/writers. Supports compliance with ISO/IEC 15693 and supports working in low-temperature environments.
Product Features | |
| Chip: ST25R3911B | Size: 300*50mm |
| Communication protocol: ISO/IEC 15693 | Package: cable |
Core Function Application Area | |
| smart refrigerator | smart home |
| Smart Appliances |
Specifications | |
| 1. Communication protocol: ISO/IEC | 2. Working frequency: 13.56MHz |
| 3. Number of read and write tags: 16pcs tags (tag antenna size: 26*11mm) | 4. Input power supply voltage: DC 12V |
| 5. With anti-collision function | 6. Reading and writing distance: <20mm |
| 7. Data transfer rate: 53 kbit/s | 8. High data integrity: 16bit CRC, parity |
| 9. Support NFC Forum Type2 Tag standard tags to form a complete reading and writing system | 10. Support label: ST25DV series / ICODE SLIX |
| 11. Working temperature range: -20°C-85°C |
