NFC dual interface module

ZD-FN3 is the second generation NFC dual interface label and channel module developed by Guangdong Zhongneng IoT Technology Co., Ltd., which complies with the ISO/IEC14443-A protocol. The module integrates channel function and dual interface label function. Suitable for close range data communication. As a module with integrated channel function and dual interface label function, it is suitable for various user scenarios. Typical access devices include home appliances, attendance machines, access control, advertising machines, mobile terminals, and human-machine interaction devices.

Product Features
Chip: FM11NT082C	Communication protocol: ISO/IEC14443-A
Package: cable

Core functions
Smart Home/Home Appliances	smart door lock
Smart business	Smart kitchen appliances
Sports Health

Specifications
1. Communication protocol: ISO/IEC 14443-A	2. Working frequency: 13.56MHz
3. Two channel working modes can be selected: ISO14443-3 mode, ISO14443-4 mode;	4. Data transfer rate: 106Kbps
5. Use 16bit CRC to ensure data integrity	6. Support fast anti-collision function
7. Working voltage range: 2.2V-3.6V	8. Support I2C external communication interface, support 100K and 400K communication rate
9. Working temperature: -40 to 85°C	10. Working humidity: ≤95%RH
