Bluetooth module
The ZD-FrB2 series low-power Bluetooth module is a low-power and high-performance module developed by Guangdong Zhongneng IoT Technology Co., Ltd. for IoT applications that supports Bluetooth 5.1 protocol. It mainly consists of highly integrated Bluetooth chips and a small number of peripheral circuits. The module is packaged with stamp holes, and thanks to the use of high-performance ceramics, the overall size of the module is small. The ZD-FrB2 has rich peripheral interfaces and is flexible to use, reducing a lot of preliminary research and development work, and easily achieving Bluetooth application development.
Product Features | |
| Chip: Fr8003 | Size: 16mm*24mm*2.5mm |
| Communication protocol: BLE 5.1 | Package: stamp hole |
Core Function Application Area | |
| outdoor travel | smart home |
| Smart Appliances | smart lighting |
Specifications | |
| 1. Single-mode Bluetooth 5.1 | 2. Support host mode, slave mode, master-slave mode |
| 3. Voltage: 1.8V~4.3V | 4. Maximum output power: 10dBm |
| 5. RX sensitivity: -97dBm typical | 6. Ultra-low circuit power consumption: 1) Standby state: <5uA 2) Shutdown state: <1uA |
| 7. Programmable ARM Cortex-M3 processor, support customer in-depth development |
