Knob Screen Module
ZDH-1301 is a color screen control panel developed by Zhongneng IoT for upgrading household appliances, which uses knobs to control the product; Solve the problem of upgrading household appliances, and upgrade the previous Nixie tube display screen to color screen.
Product Features | |
| Chip: Fr8008GP | Dimensions: outer diameter 47mm, height 24.8mm |
| Communication protocol: Bluetooth | Package: HY2.0-6P socket |
Core Function Application Area | |
| smart air fryer | smart oven |
| smart rice cooker |
Specifications | |
| 1. Storage: 8MB flash, 20KB RAM | 2. Rotary encoder: A, B, Z three-wire system |
| 3. Button: confirm button | 4. Screen size: 1.6 inches round |
| 5. Display resolution: 400*400 pixel | 6. Display color: 65K |
| 7. Input voltage: 5V | 8. Working temperature: -20℃-70℃ |
| 9. Working humidity: 10%-90%RH | 10. Weight: 35g |
